250V
[FA-] TTY-S, TTYC-S, TTYCY-S
[FA-] TTPY-S, TTPYC-S, TTPYCY-S
Standards
JISC 3410-1999
IEC 60332-1
IEC 60332-3 Cat.A(for FA-type)
Cable Construction
Conductor |
TT |
Tinned annealed stranded copper (TTY-type) Tinned annealed stranded |
Insulation |
|
60°C PVC(TTY-type)/ 85°C EPR(TTPY-type) as per JIS C 3401 |
Twisting |
|
Two Insulated cores shall be twisted together to form a pair |
Individual shield |
-S |
Tinned copper wire braid |
Cabling |
|
Twisted pairs shall be cabled. |
Bedding |
Y |
PVC as per JIS C 3401 |
Armor |
C |
Galvanized steel wire braid |
Sheath |
Y |
PVC as per JIS C 3401 |
Core identification |
|
Printed pair number and Alphabet letter on the white insulation. |
Outer sheath color |
|
Black |
Cable Parameter
(FA-) TTY-S,TTPY-S
| No. of pair, Triad or Quad |
Conductor | Thick. of insulation |
Dia. of shield wire |
Thick. of bedding |
(FA-) TTY-S,TTPY-S | ||||
| Size | Construction | O.D | Nom. overall dia |
Tolerance | Cable Weight |
||||
| mm² | No./mm | mm | mm | mm | mm | mm | mm | kg/km | |
2 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.3 |
14.4 |
0.6 |
200 |
4 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.4 |
17.4 |
0.7 |
370 |
7 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.5 |
20.9 |
0.9 |
550 |
10 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.8 |
27.4 |
1.1 |
880 |
14 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.8 |
29.8 |
1.2 |
1190 |
19 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2 |
33.6 |
1.4 |
1470 |
24 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.2 |
39.8 |
1.6 |
1930 |
30 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.3 |
42.4 |
1.7 |
2280 |
37 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.4 |
46 |
1.8 |
2740 |
48 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.7 |
53.3 |
1.9 |
3590 |
(FA-) TTYC-S,TTPYC-S
| No. of pair, Triad or Quad | Conductor | Thick. of insulation | Dia. of shield wire | Thick. of bedding | Dia. of steel wire | (FA-) TTYC-S,TTPYC-S | ||||
| Size | Construction | O.D | Nom.overall dia | Tolerance | Cable Weight | |||||
| mm² | No./mm | mm | mm | mm | mm | mm | mm | mm | kg/km | |
| 2 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 1.3 | 0.3 | 16 | 0.7 | 320 |
| 4 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 1.4 | 0.3 | 18.7 | 0.7 | 490 |
| 7 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 1.5 | 0.3 | 22.2 | 0.9 | 690 |
| 10 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 1.8 | 0.3 | 28.7 | 1.1 | 1070 |
| 14 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 1.8 | 0.3 | 31.1 | 1.2 | 1400 |
| 19 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 2 | 0.4 | 35.4 | 1.4 | 1780 |
| 24 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 2.2 | 0.4 | 41.6 | 1.6 | 2300 |
| 30 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 2.3 | 0.4 | 44.2 | 1.7 | 2680 |
| 37 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 2.4 | 0.4 | 47.8 | 1.8 | 3170 |
| 48 | 0.75 | 7/0.37 | 1.1 | 0.7 | 0.14 | 2.7 | 0.4 | 55.1 | 1.9 | 4090 |
(FA-) TTYCY-S,TTPYCY-S
| No. of pair, Triad or Quad |
Conductor | Thick. of insulation |
Dia. of shield wire |
Thick. of bedding |
Dia. of steel wire |
Thick. of covering |
(FA-)TTYCY-S,TTPYCY-S | ||||
| Size | Construction | O.D | Nom. overall dia |
Tolerance | Cable Weight |
||||||
| mm² | No./mm | mm | mm | mm | mm | mm | mm | mm | mm | kg/km | |
2 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.3 |
0.3 |
1 |
18.1 |
0.8 |
375 |
4 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.4 |
0.3 |
1.1 |
21.1 |
0.8 |
595 |
7 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.5 |
0.3 |
1.2 |
24.8 |
1 |
825 |
10 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.8 |
0.3 |
1.3 |
31.5 |
1.3 |
1250 |
14 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
1.8 |
0.3 |
1.4 |
34.1 |
1.4 |
1610 |
19 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2 |
0.4 |
1.5 |
38.8 |
1.6 |
2050 |
24 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.2 |
0.4 |
1.6 |
45.2 |
1.7 |
2640 |
30 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.3 |
0.4 |
1.7 |
48 |
1.8 |
3060 |
37 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.4 |
0.4 |
1.8 |
51.8 |
1.9 |
3600 |
48 |
0.75 |
7/0.37 |
1.1 |
0.7 |
0.14 |
2.7 |
0.4 |
2 |
59.5 |
2 |
4630 |
